OpenKM Preview Problem ,Chinese characters garbled

[kinghuangworld]

Dear Sir,

I am getting the Preview Problem,.doc and .xls files Can show letters and numbers, but Chinese character display box . Chinese character display in pdf filer ok, large pdf documents can not preview.


My configuration is:

OpemKM 5.1.9 working on centos 6.2 using openoffice 3.4 with Chinese language pack as the previewer.

Code: Select all

system.ghostscript.ps2pdf String /usr/local/bin/ps2pdf -T 9 -f ${fileIn} -o ${fileOut}
system.imagemagick.convert String /usr/local/bin/convert
system.ocr String /usr/local/bin/tesseract${fileIn} ${fileOut}
system.openoffice.dictionary String /opt/openoffice.org/basis3.4/share/wordbook
system.openoffice.path String /opt/openoffice.org3
system.swftools.pdf2swf String /usr/local/bin/pdf2swf -T 9 -f ${fileIn} -o ${fileOut}

Configuration check
•system.swftools.pdf2swf
OK - /usr/local/bin/pdf2swf
•system.imagemagick.convert
OK - /usr/local/bin/convert
•system.ocr
Can't read or execute: /usr/local/bin/tesseract${fileIn} ??
•system.openoffice.path
OK - /opt/openoffice.org3/program/soffice.bin

[jllort]

You have installed openoffice or libreoffice with chinesse support ?

[kinghuangworld]

Thank you, I add Chinese fonts in openoffice font folder then the office file preview ok .but txt file is still garbled .does the txt file is also convert pdf by openoffice too ?

[jllort]

Try txt to pdf conversion with openoffice to see if goes right, then try pdf2swf to test swf conversion ( this second from terminal ).That's the process is done by openkm and we'll see the origin of the problem.

[kinghuangworld]

I Tried txt to pdf conversion with openoffice is garbled. does txt font directory not in openoffice ?

[jllort]

Have you installed openoffice with chinese support language pack ? try open file with openoffice directly
